7201J2V4GE1
RoHS
RoHS compliant
RoHS compliantPackage /
Category Switches / Rocker Switches
Description
SWITCH ROCKER DPDT 5A 120V
PDF
/
Inventory: 2123
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Dimensions
Length 16.86mm
Technical
Actuator Marking No Marking
Max Voltage Rating (DC) 28V
Throw Configuration DPDT
Electrical Life 100,000 Cycles
Max Current Rating 5A
Max Voltage Rating (AC) 250V
Color - Actuator/Cap White
Switch Function On-On
Circuit DPDT
Actuator Type Paddle
Voltage - Rated AC 120V
Termination Style PC Pin
Current Rating 5A
Depth 11.43mm
Current Rating (Amps) 5A AC/DC
Voltage - Rated DC 28V
Min Operating Temperature -30°C
Max Operating Temperature 85°C
Termination PC Pin
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Feature Epoxy Sealed Terminals
Series 7000
Published 2008
Packaging Bulk
Operating Temperature -30°C~85°C
Physical
Actuator Material Nylon
Housing Material Stainless Steel
Mounting Type Through Hole
Mount Brackets, Through Hole
Contact Plating Gold
Contact Material Silver
Supply Chain
Factory Lead Time 14 Weeks
