7201J1V4ME2
RoHS
/
Package /
Category Switches / Rocker Switches
Description
Switch Rocker ON None ON DPDT PC Pins Long Rocker 5A 250VAC 28VDC
PDF
/
Inventory: 9340
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 11 Weeks
Physical
Contact Material Silver
Contact Plating Lead, Silver, Tin
Mount Brackets, Through Hole
Mounting Type Through Hole
Housing Material Stainless Steel
Actuator Material Nylon
Manufacturer Package Identifier 7201J1V4ME2
Technical
Operating Temperature -30°C~85°C
Packaging Bulk
Published 2006
Series 7000
Feature Epoxy Sealed Terminals
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination PC Pins
Voltage - Rated DC 28V
Current Rating (Amps) 5A AC/DC
Orientation Straight
Depth 11.43mm
Current Rating 5A
Termination Style PC Pin
Voltage - Rated AC 120V
Actuator Type Concave (Standard V)
Circuit DPDT
Switch Function On-On
Contact Resistance 10mOhm
Color - Actuator/Cap Black
Max Voltage Rating (AC) 250V
Max Current Rating 5A
Electrical Life 100,000 Cycles
Max Voltage Rating (DC) 28V
Actuator Marking No Marking
Life (Cycles) 40000 cycles
Dimensions
Height 21.06mm
Length 16.87mm
Compliance
RoHS Status Non-RoHS Compliant
Alternative Model
