7101J61ZBE22
RoHS
RoHS compliant
RoHS compliantPackage /
Category Switches / Rocker Switches
Description
Paddle 7000 Black Panel Mount Snap-In Rocker Switch 15.62mm 0.4VA AC/DC 20V -30C~85C
PDF
/
Buying Options
Total Price: USD $6.78
Unit Price: USD $6.781129
≥1 USD $6.781129
≥200 USD $2.624487
≥500 USD $2.532584
≥1000 USD $2.486633
Inventory: 7333
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Radiation Hardening No
Dimensions
Length 19.43mm
Technical
Actuator Marking No Marking
Max Voltage Rating (DC) 20V
Electrical Life 100,000 Cycles
Max Voltage Rating (AC) 20V
Color - Actuator/Cap Black
Panel Cutout Dimensions Rectangular - 15.24mm x 12.70mm
Switch Function On-On
Circuit SPDT
Actuator Type Paddle
Voltage - Rated AC 20V
Termination Style Solder Lug
Depth 15.62mm
Orientation Straight
Current Rating (Amps) 0.4VA AC/DC
Voltage - Rated DC 20V
Power Rating 400mW
Termination Solder
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Feature Epoxy Sealed Terminals
Series 7000
Published 2015
Packaging Bulk
Operating Temperature -30°C~85°C
Physical
Actuator Material Nylon
Housing Material Stainless Steel
Mounting Type Panel Mount, Snap-In
Mount Panel, Snap in
Contact Plating Gold
Supply Chain
Factory Lead Time 14 Weeks
