7101J2ZBE2
RoHS
RoHS compliant
RoHS compliantPackage /
Category Switches / Rocker Switches
Description
SWITCH ROCKER SPDT 0.4VA 20V
PDF
/
Inventory: 967
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Dimensions
Length 29.36mm
Technical
Actuator Marking No Marking
Max Voltage Rating (DC) 20V
Electrical Life 100,000 Cycles
Max Voltage Rating (AC) 20V
Color - Actuator/Cap Black
Panel Cutout Dimensions Rectangular - 17.96mm x 10.62mm
Switch Function On-On
Circuit SPDT
Actuator Type Paddle
Voltage - Rated AC 20V
Termination Style Solder Lug
Depth 9.27mm
Orientation Straight
Current Rating (Amps) 0.4VA AC/DC
Voltage - Rated DC 20V
Power Rating 400mW
Termination Solder
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Feature Epoxy Sealed Terminals
Series 7000
Published 2015
Packaging Bulk
Operating Temperature -30°C~85°C
Physical
Actuator Material Nylon
Housing Material Stainless Steel
Mounting Type Panel Mount, Flange
Mount Flanges, Panel
Contact Plating Gold
Supply Chain
Factory Lead Time 14 Weeks
