7101J1ABE1
RoHS
RoHS compliant
RoHS compliantPackage /
Category Switches / Rocker Switches
Description
Switch Rocker ON None ON SPDT PC Pins Long Rocker 20VAC 20VDC 0.4VA
PDF
/
Inventory: 952
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Technical
Actuator Marking No Marking
Max Voltage Rating (DC) 20V
Throw Configuration SPDT
Electrical Life 100,000 Cycles
Max Voltage Rating (AC) 20V
Color - Actuator/Cap White
Switch Function On-On
Circuit SPDT
Actuator Type Concave (Standard V)
Voltage - Rated AC 20V
Termination Style PC Pin
Orientation Right Angle
Current Rating (Amps) 0.4VA AC/DC
Voltage - Rated DC 20V
Power Rating 400mW
Min Operating Temperature -30°C
Max Operating Temperature 85°C
Termination PC Pin
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Feature Epoxy Sealed Terminals
Series 7000
Published 2010
Packaging Bulk
Operating Temperature -30°C~85°C
Physical
Actuator Material Nylon
Housing Material Stainless Steel
Mounting Type Through Hole, Right Angle
Mount Brackets, Through Hole
Contact Plating Gold
Supply Chain
Factory Lead Time 14 Weeks
