7101J10Z3BE2
RoHS
/
Package /
Category Switches / Rocker Switches
Description
Switch Rocker ON None ON SPDT Quick Connect Long Rocker 20VAC 20VDC 0.4VA
PDF
/
Inventory: 5427
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 14 Weeks
Physical
Contact Plating Gold
Mount Flanges, Panel
Mounting Type Panel Mount, Flange
Housing Material Stainless Steel
Actuator Material Nylon
Technical
Operating Temperature -30°C~85°C
Packaging Bulk
Published 2008
Series 7000
Feature Epoxy Sealed Terminals
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination Quick Connect
Max Operating Temperature 85°C
Min Operating Temperature -30°C
Power Rating 400mW
Voltage - Rated DC 20V
Current Rating (Amps) 0.4VA AC/DC
Depth 15.11mm
Termination Style Quick Connect - 0.062 (1.5mm)
Voltage - Rated AC 20V
Actuator Type Concave (Curved)
Circuit SPDT
Switch Function On-On
Panel Cutout Dimensions Rectangular - 34.92mm x 16.46mm
Color - Actuator/Cap Black
Max Voltage Rating (AC) 20V
Electrical Life 100,000 Cycles
Throw Configuration SPDT
Max Voltage Rating (DC) 20V
Actuator Marking No Marking
Dimensions
Length 47.63mm
Compliance
RoHS Status Non-RoHS Compliant
