C6066ALBR3
RoHS
RoHS compliant
RoHS compliantPackage /
Category Switches / Rocker Switches
Description
SWITCH ROCKER SPDT 20A 277V
PDF
/
Inventory: 8552
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Dimensions
Actuator Length 0.315 inch
Length - Termination 0.382 inch
Body Height 30mm
Technical
Actuator Marking No Marking
Contact Voltage(AC)-Max 277V
Contact Current(AC)-Max 20A
Switch Type ROCKER SWITCH
Electrical Life 10000 Cycle(s)
Dielectric Withstanding Voltage 3000VAC V
Sealing IP44
Illumination Type, Color Neon, Red
Illumination Voltage (Nominal) 250VAC
Color - Actuator/Cap Red
Insulation Resistance 20000000Ohm
Contact Resistance 0.1mOhm
Panel Cutout Dimensions Rectangular - 30.10mm x 22.20mm
Switch Function On-On
Circuit SPDT
Actuator Type Flat - Illuminated
Body Breadth 25 mm
Body Length or Diameter 31.5mm
Voltage - Rated AC 277V
Termination Style Quick Connect - 0.250 (6.3mm)
Ingress Protection Splash Proof
Current Rating (Amps) 20A AC
HTS Code 8536.50.90.65
ECCN Code EAR99
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Series 6050
Published 2016
Packaging Bulk
Physical
End Contact Material SILVER ALLOY
Center Contact Material SILVER ALLOY
Insulation Material NYLON
Surface Mount NO
Mounting Type Panel Mount, Snap-In
Supply Chain
Factory Lead Time 24 Weeks
