C5503AABR3
RoHS
RoHS compliant
RoHS compliantPackage /
Category Switches / Rocker Switches
Description
SWITCH ROCKER SPST 16A 250V
PDF
/
Buying Options
Total Price: USD $3.12
Unit Price: USD $3.123389
≥1 USD $3.123389
≥250 USD $1.247255
≥500 USD $1.205242
Inventory: 6063
Minimum: 1
-
+
Technical Details
Physical
Mounting Type Panel Mount, Snap-In
Surface Mount NO
Technical
Packaging Bulk
Published 2016
Series 5500
Part Status Discontinued
Moisture Sensitivity Level (MSL) 1 (Unlimited)
ECCN Code EAR99
HTS Code 8536.50.90.65
Current Rating (Amps) 16A AC
Termination Style Quick Connect - 0.250 (6.3mm)
Voltage - Rated AC 250V
Body Length or Diameter 30.2mm
Body Breadth 14 mm
Actuator Type Concave (Curved) - Illuminated
Circuit SPST
Switch Function On-Off
Panel Cutout Dimensions Rectangular - 27.30mm x 12.30mm
Color - Actuator/Cap Red
Illumination Voltage (Nominal) 250VAC
Illumination Type, Color Neon, Red
Switch Type ROCKER SWITCH
Contact Current(AC)-Max 15A
Actuator Marking No Marking
Dimensions
Body Height 19.5mm
Compliance
RoHS Status ROHS3 Compliant
