C1560WABB
RoHS
RoHS compliant
RoHS compliantPackage /
Category Switches / Rocker Switches
Description
Concave (Curved) 1550 Black Panel Mount Snap-In Rocker Switch 0.299inch 16A 250V 0.5HP@125VAC
PDF
/
Buying Options
Total Price: USD $21.57
Unit Price: USD $21.568321
≥1 USD $21.568321
≥250 USD $8.60606
≥500 USD $8.318534
≥1000 USD $8.176741
Inventory: 1515
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Dimensions
Actuator Length 0.299 inch
Length - Termination 0.358 inch
Technical
Contact (AC) Max Power Rating R Load 0.5HP@125VAC
Actuator Marking No Marking
Contact Voltage(AC)-Max 250V
Contact Current(AC)-Max 16A
Switch Type ROCKER SWITCH
Contact Voltage(DC)-Max 24V
Contact Current(DC)-Max 10A
Color - Actuator/Cap Black
Insulation Resistance 20000000Ohm
Contact Resistance 0.1mOhm
Panel Cutout Dimensions Rectangular - 27.30mm x 22.40mm
Switch Function On-On
Circuit DPDT
Actuator Type Concave (Curved)
Voltage - Rated AC 250V
Termination Style Quick Connect - 0.250 (6.3mm)
Ingress Protection Splash Proof
Current Rating (Amps) 16A AC 10A DC
Voltage - Rated DC 24V
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Series 1550
Published 2016
Packaging Bulk
Physical
End Contact Material SILVER ALLOY
Center Contact Material SILVER ALLOY
Actuator Material POLYCARBONATE
Insulation Material NYLON
Surface Mount NO
Mounting Type Panel Mount, Snap-In
Supply Chain
Factory Lead Time 24 Weeks
