C1522ABBB
RoHS
RoHS compliant
RoHS compliantPackage /
Category Switches / Rocker Switches
Description
Concave (Curved) 1500 Black Panel Mount Snap-In Rocker Switch 0.299inch 16A 250V 0.5HP@125VAC
PDF
/
Inventory: 5724
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 24 Weeks
Physical
Mounting Type Panel Mount, Snap-In
Surface Mount NO
Insulation Material NYLON
Actuator Material POLYCARBONATE
Center Contact Material SILVER ALLOY
End Contact Material SILVER ALLOY
Technical
Packaging Bulk
Published 2016
Series 1500
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Voltage - Rated DC 24V
Current Rating (Amps) 16A AC 10A DC
Termination Style Quick Connect - 0.250 (6.3mm)
Voltage - Rated AC 250V
Actuator Type Concave (Curved)
Circuit SPDT
Switch Function Mom-Off-Mom
Panel Cutout Dimensions Rectangular - 30.10mm x 11.10mm
Contact Resistance 0.1mOhm
Insulation Resistance 20000000Ohm
Color - Actuator/Cap Black
Contact Current(DC)-Max 10A
Contact Voltage(DC)-Max 24V
Switch Type ROCKER SWITCH
Contact Current(AC)-Max 16A
Contact Voltage(AC)-Max 250V
Actuator Marking No Marking
Contact Function ON-OFF-ON
Contact (AC) Max Power Rating R Load 0.5HP@125VAC
Actuator Finish MATTE
Dimensions
Length - Termination 0.358 inch
Actuator Length 0.299 inch
Compliance
RoHS Status ROHS3 Compliant
