HB110C3NBBR
RoHS
RoHS compliant
RoHS compliantPackage /
Category Switches / Rocker Switches
Description
Concave (Curved) HB Black Red Panel Mount Snap-In Rocker Switch 20A 250V 20mOhm -20C~85C
PDF
/
Inventory: 9505
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
Ratings IP42
RoHS Status ROHS3 Compliant
Technical
Actuator Marking ON OFF, Vertical
Throw Configuration SPST
Electrical Life 10,000 Cycles
Max Voltage Rating (AC) 250V
Color - Actuator/Cap Black, Red
Contact Resistance 20mOhm
Panel Cutout Dimensions Rectangular - 28.60mm x 13.59mm
Switch Function On-Off
Circuit SPST
Actuator Type Concave (Curved)
Voltage - Rated AC 125V
Termination Style Quick Connect - 0.250 (6.3mm)
Current Rating 20A
Ingress Protection IP42
Orientation Straight
Current Rating (Amps) 20A AC
Min Operating Temperature -20°C
Max Operating Temperature 85°C
Termination Quick Connect
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Feature Two-Tone Rocker
Series HB
Packaging Bulk
Operating Temperature -20°C~85°C
Physical
Actuator Material Nylon, Polycarbonate
Mounting Type Panel Mount, Snap-In
Mount Panel, Snap in
Contact Material Cadmium, Silver
Supply Chain
Factory Lead Time 19 Weeks
