TRF4903PWRG4
RoHS
RoHS compliant
RoHS compliantPackage 24-TSSOP (0.173, 4.40mm Width)
Category RF/IF and RFID / RF Transmitters
Description
RF TX IC FSK 315/433MHZ 24TSSOP
PDF
/
Inventory: 3035
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
Lead Free Contains Lead
RoHS Status ROHS3 Compliant
Dimensions
Width 4.4mm
Length 7.9mm
Height Seated (Max) 1.2mm
Technical
Antenna Connector PCB, Surface Mount
Modulation or Protocol FSK, OOK
Current - Transmitting 35mA
Power - Output -12dBm~8dBm
Telecom IC Type RF AND BASEBAND CIRCUIT
Data Interface PCB, Surface Mount
Supply Current-Max 0.043mA
Power Supplies 2.7V
Operating Supply Voltage 3.3V
Qualification Status Not Qualified
Pin Count 24
Base Part Number TRF4903
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Frequency 315MHz 433MHz 868MHz 915MHz
Depth 4.5mm
Terminal Pitch 0.65mm
Supply Voltage 2.7V
Number of Functions 1
Peak Reflow Temperature (Cel) NOT SPECIFIED
Terminal Form GULL WING
Terminal Position DUAL
Voltage - Supply 2.2V~3.6V
Subcategory Other Telecom ICs
HTS Code 8542.39.00.01
Number of Terminations 24
Moisture Sensitivity Level (MSL) 2 (1 Year)
Part Status Obsolete
Pbfree Code no
Packaging Tape & Reel (TR)
Operating Temperature -40°C~85°C
Physical
Weight 90.009736mg
Number of Pins 24
Surface Mount YES
Package / Case 24-TSSOP (0.173, 4.40mm Width)
