TRF4400PWRG4
RoHS
RoHS compliant
RoHS compliantPackage 24-TSSOP (0.173, 4.40mm Width)
Category RF/IF and RFID / RF Transmitters
Description
Tape & Reel (TR) TRF4400 FM FSK PCB Surface Mount RF Transmitter 7.8mm 3.3V -7dBm~12dBm 433MHz
PDF
/
Inventory: 2213
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Dimensions
Width 4.4mm
Length 7.8mm
Height Seated (Max) 1.2mm
Technical
Antenna Connector PCB, Surface Mount
Modulation or Protocol FM, FSK
Current - Transmitting 57mA
Power - Output -7dBm~12dBm
Telecom IC Type RF AND BASEBAND CIRCUIT
Data Interface PCB, Surface Mount
Supply Current-Max 0.075mA
Power Supplies 3V
Operating Supply Voltage 3.3V
Qualification Status Not Qualified
Pin Count 24
Base Part Number TRF4400
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Frequency 433MHz
Terminal Pitch 0.65mm
Supply Voltage 3V
Number of Functions 1
Peak Reflow Temperature (Cel) NOT SPECIFIED
Terminal Form GULL WING
Terminal Position DUAL
Voltage - Supply 2.2V~3.6V
Technology CMOS
Subcategory Other Telecom ICs
HTS Code 8542.39.00.01
Number of Terminations 24
Moisture Sensitivity Level (MSL) 2 (1 Year)
Part Status Obsolete
Packaging Tape & Reel (TR)
Operating Temperature -20°C~60°C
Physical
Number of Pins 24
Surface Mount YES
Package / Case 24-TSSOP (0.173, 4.40mm Width)
