CC1150RSTRG3
RoHS
RoHS compliant
RoHS compliantPackage 16-QFN
Category RF/IF and RFID / RF Transmitters
Description
RF Transmitter ASK/FSK/OOK/GFSK/MSK 1.8V/2.5V/3.3V 16-Pin VQFN EP T/R
PDF
/
Inventory: 2590
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
Lead Free Contains Lead
RoHS Status ROHS3 Compliant
Radiation Hardening No
Dimensions
Length 4mm
Height Seated (Max) 0.95mm
Technical
Antenna Connector PCB, Surface Mount
Modulation or Protocol 2-FSK, ASK, GFSK, MSK, OOK
Current - Transmitting 28.1mA @ 10 dBm
Data Rate (Max) 500kBaud
Power - Output -30dBm~10dBm
Telecom IC Type RF AND BASEBAND CIRCUIT
Data Interface PCB, Surface Mount
Power Supplies 1.8/3.6V
Operating Supply Voltage 3.3V
Pin Count 16
Base Part Number CC1150
Frequency 300MHz~348MHz 400MHz~464MHz 800MHz~928MHz
Depth 4mm
Terminal Pitch 0.65mm
Supply Voltage 3V
Number of Functions 1
Peak Reflow Temperature (Cel) 260
Terminal Position QUAD
Voltage - Supply 1.8V~3.6V
Technology CMOS
Subcategory Other Telecom ICs
HTS Code 8542.39.00.01
Applications AMR, ISM, RKE, SRD
Number of Terminations 16
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Part Status Obsolete
Pbfree Code yes
JESD-609 Code e4
Packaging Tape & Reel (TR)
Operating Temperature -40°C~85°C
Physical
Number of Pins 16
Package / Case 16-QFN
Mount Surface Mount
Contact Plating Gold
