CC1150-RTR1
RoHS
RoHS compliant
RoHS compliantPackage 16-QFN
Category RF/IF and RFID / RF Transmitters
Description
RF Transmitter ASK/FSK/OOK/GFSK/MSK 1.8V/2.5V/3.3V 16-Pin VQFN EP T/R
PDF
/
Buying Options
Total Price: USD $26.49
Unit Price: USD $26.4898
≥1 USD $26.4898
≥10 USD $21.736
≥100 USD $21.05675
≥500 USD $20.3775
≥1000 USD $19.69825
Inventory: 1768
Minimum: 1
-
+
Technical Details
Technical
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 16
Applications AMR, ISM, RKE, SRD
HTS Code 8542.39.00.01
Subcategory Other Telecom ICs
Technology CMOS
Voltage - Supply 1.8V~3.6V
Terminal Position QUAD
Peak Reflow Temperature (Cel) 260
Number of Functions 1
Supply Voltage 3V
Terminal Pitch 0.65mm
Depth 4mm
Frequency 300MHz~348MHz 400MHz~464MHz 800MHz~928MHz
Base Part Number CC1150
Pin Count 16
Operating Supply Voltage 3.3V
Power Supplies 1.8/3.6V
Data Interface PCB, Surface Mount
Density 0 b
Telecom IC Type RF AND BASEBAND CIRCUIT
Power - Output -30dBm~10dBm
Data Rate (Max) 500kBaud
Current - Transmitting 28.1mA @ 10 dBm
Modulation or Protocol 2-FSK, ASK, GFSK, MSK, OOK
Antenna Connector PCB, Surface Mount
Part Status Obsolete
JESD-609 Code e4
Packaging Tape & Reel (TR)
Operating Temperature -40°C~85°C
Dimensions
Height Seated (Max) 0.95mm
Length 4mm
Physical
Number of Pins 16
Package / Case 16-QFN
Mount Surface Mount
Contact Plating Gold
Compliance
Lead Free Contains Lead
RoHS Status ROHS3 Compliant
Radiation Hardening No
