CC1070RSQ
RoHS
RoHS compliant
RoHS compliantPackage 20-QFN Exposed Pad
Category RF/IF and RFID / RF Transmitters
Description
RF TX IC ASK 402-470MHZ 20QFN
PDF
/
Buying Options
Total Price: USD $8.06
Unit Price: USD $8.05505
≥1 USD $8.05505
≥10 USD $6.60915
≥100 USD $6.403
≥500 USD $6.1959
≥1000 USD $5.98975
Inventory: 1539
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Contains Lead
RoHS Status ROHS3 Compliant
Radiation Hardening No
Dimensions
Thickness 900μm
Width 5mm
Length 5mm
Height Seated (Max) 1mm
Technical
Antenna Connector PCB, Surface Mount
Modulation or Protocol ASK, FSK, GFSK, OOK
Current - Transmitting 33.1mA
Data Rate (Max) 153.6kBaud
Power - Output -20dBm~10dBm
Telecom IC Type RF AND BASEBAND CIRCUIT
Data Interface PCB, Surface Mount
Operating Supply Voltage 3V
Pin Count 20
Base Part Number CC1070
Frequency 402MHz~470MHz 804MHz~940MHz
Depth 5mm
Supply Voltage 3V
Number of Functions 1
Terminal Position QUAD
Voltage - Supply 2.3V~3.6V
Technology CMOS
Subcategory Other Telecom ICs
HTS Code 8542.39.00.01
Applications ISM
Number of Terminations 20
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Part Status Not For New Designs
Packaging Tube
Operating Temperature -40°C~105°C
Physical
Number of Pins 20
Package / Case 20-QFN Exposed Pad
Mount Surface Mount
Supply Chain
Lifecycle Status NRND (Last Updated: 2 days ago)
