BH1417F-E2
RoHS
RoHS compliant
RoHS compliantPackage 22-SOIC (0.213, 5.40mm Width)
Category RF/IF and RFID / RF Transmitters
Description
RF XMITTER FM 76-90MHZ 22SOIC
PDF
/
Buying Options
Total Price: USD $0.95
Unit Price: USD $0.95
≥1 USD $0.95
≥10 USD $0.779
≥100 USD $0.75525
≥500 USD $0.73055
≥1000 USD $0.70585
Inventory: 26404
Minimum: 1
-
+
Technical Details
Physical
Mount Surface Mount
Package / Case 22-SOIC (0.213, 5.40mm Width)
Number of Pins 22
Technical
Operating Temperature -40°C~85°C
Packaging Tape & Reel (TR)
Published 2003
Part Status Not For New Designs
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Max Operating Temperature 85°C
Min Operating Temperature -40°C
Applications Wireless Audio Link LSI
Voltage - Supply 4V~6V
Frequency 76MHz~90MHz 87.5MHz~108MHz
Operating Supply Voltage 6V
Nominal Supply Current 21mA
Data Interface PCB, Surface Mount
Power - Output -7dBm
Current - Transmitting 20mA
Modulation or Protocol FM
Antenna Connector PCB, Surface Mount
Dimensions
Length 13.6mm
Width 5.4mm
Thickness 1.8mm
Compliance
RoHS Status ROHS3 Compliant
Lead Free Contains Lead
