BH1415FV-E2
RoHS
RoHS compliant
RoHS compliantPackage 24-LSSOP (0.220, 5.60mm Width)
Category RF/IF and RFID / RF Transmitters
Description
RF XMITTER FM 70-120MHZ 24LSSOP
PDF
/
Buying Options
Total Price: USD $1.34
Unit Price: USD $1.34235
≥1 USD $1.34235
≥10 USD $1.102
≥100 USD $1.0678
≥500 USD $1.03265
≥1000 USD $0.99845
Inventory: 1169
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
Dimensions
Thickness 1.15mm
Width 5.6mm
Length 7.8mm
Height Seated (Max) 1.35mm
Technical
Antenna Connector PCB, Surface Mount
Modulation or Protocol FM
Current - Transmitting 28mA
Consumer IC Type CONSUMER CIRCUIT
Power - Output -7dBm
Data Interface PCB, Surface Mount
Nominal Supply Current 20mA
Supply Voltage-Min (Vsup) 4V
Supply Voltage-Max (Vsup) 6V
JESD-30 Code R-PDSO-G24
Pin Count 24
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Frequency 70MHz~120MHz
Terminal Pitch 0.65mm
Number of Functions 1
Peak Reflow Temperature (Cel) NOT SPECIFIED
Terminal Form GULL WING
Terminal Position DUAL
Voltage - Supply 4V~6V
HTS Code 8542.39.00.01
Applications Wireless Audio Link LSI
Number of Terminations 24
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Not For New Designs
Pbfree Code yes
Published 2005
Packaging Tape & Reel (TR)
Operating Temperature -40°C~85°C
Physical
Package / Case 24-LSSOP (0.220, 5.60mm Width)
Mount Surface Mount
Contact Plating Copper, Tin
