BH1415F-E2
RoHS
RoHS compliant
RoHS compliantPackage 22-SOIC (0.213, 5.40mm Width)
Category RF/IF and RFID / RF Transmitters
Description
RF XMITTER FM 70-120MHZ 22SOIC
PDF
/
Buying Options
Total Price: USD $3.75
Unit Price: USD $3.7468
≥1 USD $3.7468
≥10 USD $3.07515
≥100 USD $2.97825
≥500 USD $2.8823
≥1000 USD $2.78635
Inventory: 19508
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
Dimensions
Thickness 1.8mm
Width 5.4mm
Length 13.6mm
Height Seated (Max) 2.01mm
Technical
Antenna Connector PCB, Surface Mount
Modulation or Protocol FM
Current - Transmitting 28mA
Consumer IC Type CONSUMER CIRCUIT
Power - Output -7dBm
Data Interface PCB, Surface Mount
Nominal Supply Current 20mA
Supply Voltage-Min (Vsup) 4V
Supply Voltage-Max (Vsup) 6V
Operating Supply Voltage 6V
Pin Count 22
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Frequency 70MHz~120MHz
Terminal Pitch 1.27mm
Number of Functions 1
Peak Reflow Temperature (Cel) NOT SPECIFIED
Terminal Form GULL WING
Terminal Position DUAL
Voltage - Supply 4V~6V
HTS Code 8542.39.00.01
Applications Wireless Audio Link LSI
Number of Terminations 22
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Not For New Designs
Pbfree Code yes
Published 2003
Packaging Tape & Reel (TR)
Operating Temperature -40°C~85°C
Physical
Number of Pins 22
Package / Case 22-SOIC (0.213, 5.40mm Width)
Mount Surface Mount
Supply Chain
Factory Lead Time 8 Weeks
Alternative Model
