MAX2370ETM
RoHS
/
Package 48-WFQFN Exposed Pad
Category RF/IF and RFID / RF Transmitters
Description
Tube 1 CDMA2000 PCB Surface Mount RF Transmitter 7mm 3V 10dBm 450MHz
PDF
/
Buying Options
Total Price: USD $16.97
Unit Price: USD $16.972358
≥1 USD $16.972358
≥200 USD $6.568662
≥500 USD $6.568662
≥1000 USD $6.224614
Inventory: 1177
Minimum: 1
-
+
Technical Details
Physical
Package / Case 48-WFQFN Exposed Pad
Surface Mount YES
Technical
Operating Temperature -40°C~85°C
Packaging Tube
JESD-609 Code e0
Pbfree Code no
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 48
Terminal Finish TIN LEAD
Technology BICMOS
Voltage - Supply 2.7V~3.3V
Terminal Position QUAD
Terminal Form NO LEAD
Peak Reflow Temperature (Cel) 240
Number of Functions 1
Supply Voltage 3V
Terminal Pitch 0.5mm
Frequency 450MHz
Time@Peak Reflow Temperature-Max (s) 20
Pin Count 48
JESD-30 Code S-XQCC-N48
Qualification Status COMMERCIAL
Data Interface PCB, Surface Mount
Telecom IC Type TELECOM CIRCUIT
Power - Output 10dBm
Current - Transmitting 134mA
Modulation or Protocol CDMA2000
Antenna Connector PCB, Surface Mount
Dimensions
Height Seated (Max) 0.8mm
Length 7mm
Width 7mm
Compliance
RoHS Status Non-RoHS Compliant
