MAX2361ETM+
RoHS
RoHS compliant
RoHS compliantPackage 48-WFQFN Exposed Pad
Category RF/IF and RFID / RF Transmitters
Description
Tube 1 PCB Surface Mount PCB Surface Mount RF Transmitter 7mm 2.8V 9dBm 800MHz~2.2GHz
PDF
/
Buying Options
Total Price: USD $11.93
Unit Price: USD $11.9339
≥1 USD $11.9339
≥10 USD $9.79165
≥100 USD $9.48575
≥500 USD $9.17985
≥1000 USD $8.87395
Inventory: 2852
Minimum: 1
-
+
Technical Details
Physical
Package / Case 48-WFQFN Exposed Pad
Surface Mount YES
Technical
Operating Temperature -40°C~85°C
Packaging Tube
JESD-609 Code e0
Pbfree Code no
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 48
Terminal Finish TIN LEAD
Voltage - Supply 2.7V~3.3V
Terminal Position QUAD
Terminal Form NO LEAD
Peak Reflow Temperature (Cel) 240
Number of Functions 1
Supply Voltage 2.8V
Terminal Pitch 0.5mm
Frequency 800MHz~2.2GHz
Time@Peak Reflow Temperature-Max (s) 20
Pin Count 48
JESD-30 Code S-XQCC-N48
Qualification Status COMMERCIAL
Data Interface PCB, Surface Mount
Telecom IC Type RF AND BASEBAND CIRCUIT
Power - Output 9dBm
Current - Transmitting 146mA
Antenna Connector PCB, Surface Mount
Dimensions
Height Seated (Max) 0.8mm
Length 7mm
Width 7mm
Compliance
RoHS Status ROHS3 Compliant
