RF2516
RoHS
/
Package 16-SSOP (0.154, 3.90mm Width)
Category RF/IF and RFID / RF Transmitters
Description
RF TX IC AM 100-500MHZ 16SSOP
PDF
/
Inventory: 3827
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status RoHS Compliant
Dimensions
Width 3.9mm
Length 4.9mm
Height Seated (Max) 1.75mm
Technical
Antenna Connector PCB, Surface Mount
Modulation or Protocol AM, ASK, OOK
Current - Transmitting 10.5mA
Power - Output 10dBm
Telecom IC Type TELECOM CIRCUIT
Data Interface PCB, Surface Mount
Power Supplies 2.8V
Qualification Status Not Qualified
JESD-30 Code R-PDSO-G16
Pin Count 16
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Frequency 100MHz~500MHz
Terminal Pitch 0.635mm
Supply Voltage 2.8V
Number of Functions 1
Peak Reflow Temperature (Cel) NOT SPECIFIED
Terminal Form GULL WING
Terminal Position DUAL
Voltage - Supply 2.25V~3.6V
Technology BICMOS
Subcategory Other Telecom ICs
HTS Code 8542.39.00.01
Applications Alarm and Security Systems, RKE
ECCN Code EAR99
Number of Terminations 16
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Pbfree Code yes
Published 2009
Packaging Bulk
Operating Temperature -40°C~85°C
Physical
Surface Mount YES
Package / Case 16-SSOP (0.154, 3.90mm Width)
