T5754C-6AQJ-66
RoHS
RoHS compliant
RoHS compliantPackage 8-TSSOP, 8-MSOP (0.118, 3.00mm Width)
Category RF/IF and RFID / RF Transmitters
Description
RF Transmitter UHF ASK/FSK Transmitter 433 MHz
PDF
/
Buying Options
Total Price: USD $2.01
Unit Price: USD $2.01495
≥1 USD $2.01495
≥10 USD $1.65395
≥100 USD $1.6017
≥500 USD $1.5504
≥1000 USD $1.4991
Inventory: 10108
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
Dimensions
Width 3mm
Length 3mm
Height Seated (Max) 1.05mm
Technical
Antenna Connector PCB, Surface Mount
Modulation or Protocol ASK, FSK
Current - Transmitting 9mA
Data Rate (Max) 32kBaud
Power - Output 7.5dBm
Telecom IC Type TELECOM CIRCUIT
Data Interface PCB, Surface Mount
Operating Supply Current 8.5mA
Operating Supply Voltage 4V
JESD-30 Code S-PDSO-G8
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Frequency 429MHz~439MHz
Terminal Pitch 0.65mm
Supply Voltage 3V
Number of Functions 1
Peak Reflow Temperature (Cel) NOT SPECIFIED
Terminal Form GULL WING
Terminal Position DUAL
Voltage - Supply 2V~4V
Applications General Purpose Data Transmission Systems
Number of Terminations 8
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Part Status Discontinued
Pbfree Code yes
Published 2011
Packaging Cut Tape (CT)
Operating Temperature -40°C~125°C
Physical
Surface Mount YES
Package / Case 8-TSSOP, 8-MSOP (0.118, 3.00mm Width)
Supply Chain
Factory Lead Time 12 Weeks
