PIC12F529T39A-I/ST
RoHS
RoHS compliant
RoHS compliantPackage 14-TSSOP (0.173, 4.40mm Width)
Category RF/IF and RFID / RF Transmitters
Description
PIC12F529T39A-I/ST; 8bit PIC Microcontroller; 8MHz; 1536 words Flash; 14-Pin TSSOP
PDF
/
Buying Options
Total Price: USD $1.59
Unit Price: USD $1.5928
≥1 USD $1.5928
≥10 USD $1.4344
≥100 USD $1.3024
Inventory: 464
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
REACH SVHC No SVHC
Radiation Hardening No
Dimensions
Width 4.5mm
Length 5.1mm
Height 1.05mm
Technical
Antenna Connector PCB, Surface Mount
Modulation or Protocol FSK, OOK
Current - Transmitting 17.5mA
Data Rate (Max) 100kbps
Power - Output 10dBm
Number of Programmable I/O 5
Core Architecture PIC
Number of Timers/Counters 1
Data Interface PCB, Surface Mount
DAC Channels NO
PWM Channels NO
Data Bus Width 8b
DMA Channels NO
Has ADC YES
Bit Size 8
uPs/uCs/Peripheral ICs Type MICROCONTROLLER, RISC
Memory Type FLASH
RAM Size 201B
Speed 8 MHz
Number of I/O 6
Memory Size 64kB Flash 201b SRAM
Pin Count 14
Base Part Number PIC12F529
Time@Peak Reflow Temperature-Max (s) 40
Frequency 310MHz 433MHz 868MHz 915MHz
Supply Voltage 3V
Peak Reflow Temperature (Cel) 260
Terminal Form GULL WING
Terminal Position DUAL
Voltage - Supply 2V~3.7V
Technology CMOS
Max Power Dissipation 700mW
Applications General Purpose
Terminal Finish Matte Tin (Sn) - annealed
ECCN Code EAR99
Number of Terminations 14
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
JESD-609 Code e3
Series PIC?
Published 2012
Packaging Tube
Operating Temperature -40°C~85°C
Physical
Number of Pins 14
Surface Mount YES
Package / Case 14-TSSOP (0.173, 4.40mm Width)
Supply Chain
Factory Lead Time 24 Weeks
