TH72011KDC-BAA-000-RE
RoHS
RoHS compliant
RoHS compliantPackage 8-SOIC (0.154, 3.90mm Width)
Category RF/IF and RFID / RF Transmitters
Description
IC XMITTER 433MHZ ASK 8SOIC
PDF
/
Buying Options
Total Price: USD $27.65
Unit Price: USD $27.64975
≥1 USD $27.64975
≥10 USD $22.68695
≥100 USD $21.97825
≥500 USD $21.2686
≥1000 USD $20.5599
Inventory: 1588
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status RoHS Compliant
Dimensions
Width 3.9mm
Length 4.89mm
Height Seated (Max) 1.72mm
Technical
Antenna Connector PCB, Surface Mount
Modulation or Protocol FSK
Current - Transmitting 3.4mA~10.6mA
Data Rate (Max) 40kbps
Power - Output -12dBm~10dBm
Telecom IC Type TELECOM CIRCUIT
Data Interface PCB, Surface Mount
JESD-30 Code R-PDSO-G8
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Frequency 433MHz
Terminal Pitch 1.27mm
Supply Voltage 3V
Number of Functions 1
Peak Reflow Temperature (Cel) NOT SPECIFIED
Terminal Form GULL WING
Terminal Position DUAL
Voltage - Supply 1.95V~5.5V
HTS Code 8542.39.00.01
Applications Alarm and Security Systems, RKE
Terminal Finish Matte Tin (Sn)
Number of Terminations 8
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Last Time Buy
JESD-609 Code e3
Published 2004
Packaging Tape & Reel (TR)
Operating Temperature -40°C~125°C
Physical
Surface Mount YES
Package / Case 8-SOIC (0.154, 3.90mm Width)
Supply Chain
Factory Lead Time 12 Weeks
