MAX7057ASE+
RoHS
RoHS compliant
RoHS compliantPackage 16-SOIC (0.154, 3.90mm Width)
Category RF/IF and RFID / RF Transmitters
Description
RF TX IC ASK 300-450MHZ 16SOIC
PDF
/
Buying Options
Total Price: USD $1.8
Unit Price: USD $1.7952
≥1 USD $1.7952
≥10 USD $1.55056
≥100 USD $1.4388
≥500 USD $1.408352
Inventory: 213
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 6 Weeks
Physical
Package / Case 16-SOIC (0.154, 3.90mm Width)
Surface Mount YES
Number of Pins 16
Technical
Operating Temperature -40°C~125°C
Packaging Tube
Published 2012
Pbfree Code yes
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 16
ECCN Code EAR99
Terminal Finish NOT SPECIFIED
Applications Home Automation, Security
HTS Code 8542.39.00.01
Subcategory Other Telecom ICs
Technology CMOS
Voltage - Supply 2.1V~3.6V
Terminal Position DUAL
Terminal Form GULL WING
Peak Reflow Temperature (Cel) NOT SPECIFIED
Number of Functions 1
Supply Voltage 2.7V
Terminal Pitch 1.27mm
Frequency 300MHz~450MHz
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Base Part Number MAX7057
Pin Count 16
Qualification Status Not Qualified
Operating Supply Voltage 2.7V
Supply Current-Max 0.0237mA
Data Interface PCB, Surface Mount
Telecom IC Type TELECOM CIRCUIT
Power - Output 17dBm
Data Rate (Max) 100kbps
Current - Transmitting 12.4mA
Modulation or Protocol ASK, FSK
Antenna Connector PCB, Surface Mount
Dimensions
Height Seated (Max) 1.75mm
Length 9.9mm
Width 3.9mm
Compliance
RoHS Status ROHS3 Compliant
