MAX2850ITK+
RoHS
RoHS compliant
RoHS compliantPackage 68-TQFN Exposed Pad
Category RF/IF and RFID / RF Transmitters
Description
RF TRANSMITTER 4.9-5.9GHZ 68TQFN
PDF
/
Buying Options
Total Price: USD $49.77
Unit Price: USD $49.76955
≥1 USD $49.76955
≥10 USD $40.8367
≥100 USD $39.5599
≥500 USD $38.28405
≥1000 USD $37.0082
Inventory: 3802
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Dimensions
Width 10.1mm
Length 10.1mm
Height 750μm
Technical
Antenna Connector PCB, Surface Mount
Current - Transmitting 661mA
Power - Output -4dBm
Telecom IC Type TELECOM CIRCUIT
Data Interface PCB, Surface Mount
Operating Supply Current 60mA
Temperature Grade OTHER
Qualification Status Not Qualified
Pin Count 68
Base Part Number MAX2850
Time@Peak Reflow Temperature-Max (s) 30
Frequency 4.9GHz~5.9GHz
Terminal Pitch 0.5mm
Supply Voltage 2.85V
Number of Functions 1
Peak Reflow Temperature (Cel) 260
Terminal Form NO LEAD
Terminal Position QUAD
Voltage - Supply 2.7V~3.6V
Technology BICMOS
HTS Code 8542.39.00.01
Applications General Purpose
Min Operating Temperature -25°C
Max Operating Temperature 85°C
Terminal Finish Tin (Sn)
ECCN Code 5A991
Number of Terminations 68
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Part Status Active
Pbfree Code yes
JESD-609 Code e3
Published 2010
Packaging Tube
Physical
Number of Pins 68
Package / Case 68-TQFN Exposed Pad
Mount Surface Mount
