MAX2369EGM+TD
RoHS
RoHS compliant
RoHS compliantPackage 48-QFN Exposed Pad
Category RF/IF and RFID / RF Transmitters
Description
Tube 1 PCB Surface Mount Cellular GAIT Handsets LANs PCS TDMA WAN WLL RF Transmitter 7mm 3V 5.8dBm~12dBm 120MHz~235MHz
PDF
/
Buying Options
Total Price: USD $9.06
Unit Price: USD $9.0573
≥1 USD $9.0573
≥10 USD $7.43185
≥100 USD $7.20005
≥500 USD $6.9673
≥1000 USD $6.7355
Inventory: 11904
Minimum: 1
-
+
Technical Details
Physical
Package / Case 48-QFN Exposed Pad
Surface Mount YES
Technical
Operating Temperature -40°C~85°C
Packaging Tube
Published 2002
JESD-609 Code e3
Part Status Obsolete
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Number of Terminations 48
ECCN Code EAR99
Terminal Finish TIN
Applications Cellular, GAIT Handsets, LANs, PCS, TDMA, WAN, WLL
HTS Code 8542.39.00.01
Voltage - Supply 2.7V~5.5V
Terminal Position QUAD
Terminal Form NO LEAD
Peak Reflow Temperature (Cel) 260
Number of Functions 1
Supply Voltage 2.75V
Terminal Pitch 0.5mm
Frequency 120MHz~235MHz
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Pin Count 48
Antenna Connector PCB, Surface Mount
Current - Transmitting 6.5mA~155mA
Power - Output 5.8dBm~12dBm
Telecom IC Type RF AND BASEBAND CIRCUIT
Data Interface PCB, Surface Mount
Nominal Supply Current 155mA
Operating Supply Voltage 3V
Qualification Status Not Qualified
JESD-30 Code S-XQCC-N48
Compliance
RoHS Status ROHS3 Compliant
Dimensions
Width 7mm
Length 7mm
Height Seated (Max) 0.8mm
