ADF7012BRUZ-RL7
RoHS
RoHS compliant
RoHS compliantPackage 24-TSSOP (0.173, 4.40mm Width)
Category RF/IF and RFID / RF Transmitters
Description
Tape & Reel (TR) ADF7012 ASK FSK GFSK OOK PCB Surface Mount RF Transmitter 7.8mm 3.6V -16dBm~14dBm 75MHz~1GHz
PDF
/
Buying Options
Total Price: USD $1.72
Unit Price: USD $1.723593
≥1 USD $1.723593
≥10 USD $3.306
≥100 USD $3.20245
≥500 USD $3.0989
≥1000 USD $2.9963
Inventory: 7004
Minimum: 1
-
+
Technical Details
Technical
Nominal Supply Current 16mA
Data Interface PCB, Surface Mount
Telecom IC Type TELECOM CIRCUIT
Power - Output -16dBm~14dBm
Data Rate (Max) 179.2kbps
Current - Transmitting 35mA
Modulation or Protocol ASK, FSK, GFSK, OOK
Antenna Connector PCB, Surface Mount
Operating Supply Current 18mA
Power Supplies 2.5/3.3V
Operating Supply Voltage 3.6V
Pin Count 24
Base Part Number ADF7012
Time@Peak Reflow Temperature-Max (s) 30
Frequency 75MHz~1GHz
Depth 4.4mm
Terminal Pitch 0.65mm
Supply Voltage 3V
Number of Functions 1
Peak Reflow Temperature (Cel) 260
Terminal Form GULL WING
Terminal Position DUAL
Voltage - Supply 2.3V~3.6V
Technology CMOS
Subcategory Other Telecom ICs
HTS Code 8542.39.00.01
Applications Data Transfer, RKE, Remote Control/Security Systems
Terminal Finish Matte Tin (Sn)
ECCN Code 5A991.B
Number of Terminations 24
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code no
JESD-609 Code e3
Packaging Tape & Reel (TR)
Operating Temperature -40°C~85°C
Dimensions
Height Seated (Max) 1.2mm
Length 7.8mm
Width 4.4mm
Compliance
Radiation Hardening No
RoHS Status ROHS3 Compliant
Lead Free Contains Lead
Physical
Number of Pins 24
Surface Mount YES
Package / Case 24-TSSOP (0.173, 4.40mm Width)
Supply Chain
Lifecycle Status PRODUCTION (Last Updated: 3 weeks ago)
Factory Lead Time 8 Weeks
