WL1807MODGIMOCT
RoHS
RoHS compliant
RoHS compliantPackage 100-SMD Module
Category RF/IF and RFID / RF Transceiver Modules
Description
MODULE WIFI WILINK
PDF
/
Buying Options
Total Price: USD $23.38
Unit Price: USD $23.3816
≥1 USD $23.3816
≥10 USD $21.582
≥100 USD $19.783456
≥500 USD $18.28464
Inventory: 558
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Contains Lead
RoHS Status ROHS3 Compliant
Dimensions
Thickness 2mm
Width 13.4mm
Length 13.3mm
Height 2mm
Technical
Sensitivity (dBm) -95 dBm
Modulation CCK, DSSS, GFSK, OFDM
Current - Transmitting 238mA~510mA
Current - Receiving 49mA~85mA
Serial Interfaces SDIO, UART
RF Family/Standard Bluetooth, WiFi
Power - Output 18dBm
Telecom IC Type TELECOM CIRCUIT
Protocol 802.11a/b/g/n, Bluetooth v4.2
Data Rate 54Mbps
Interface SDIO, UART
Power Supplies 2.9/4.8V
Qualification Status Not Qualified
Base Part Number WL1807
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Frequency 2.4GHz 5GHz
Terminal Pitch 0.7mm
Supply Voltage 3.7V
Number of Functions 1
Peak Reflow Temperature (Cel) 260
Terminal Form NO LEAD
Terminal Position BOTTOM
Voltage - Supply 2.9V~4.8V
Subcategory Other Telecom ICs
Terminal Finish Nickel/Palladium/Gold (Ni/Pd/Au)
ECCN Code 5A992C
Number of Terminations 100
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Part Status Active
Pbfree Code yes
JESD-609 Code e4
Series WiLink?
Packaging Tape & Reel (TR)
Operating Temperature -40°C~85°C
Physical
Number of Pins 100
Package / Case 100-SMD Module
Mounting Type Surface Mount
Mount Surface Mount
Supply Chain
Lifecycle Status ACTIVE (Last Updated: 4 days ago)
Factory Lead Time 12 Weeks
