SPWF01SA.21
RoHS
RoHS compliant
RoHS compliantPackage Module
Category RF/IF and RFID / RF Transceiver Modules
Description
RF TXRX MODULE WIFI CHIP ANT
PDF
/
Inventory: 1652
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Contact Plating Gold
Mount Surface Mount
Mounting Type Surface Mount
Package / Case Module
Number of Pins 30
Technical
Operating Temperature -40°C~85°C
Packaging Tray
Part Status Obsolete
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Number of Terminations 25
ECCN Code 5A992.C
Terminal Position UNSPECIFIED
Number of Functions 1
Supply Voltage 3.3V
Frequency 2.4GHz
Base Part Number SPWF01
JESD-30 Code R-XXMA-N25
Operating Supply Voltage 3.3V
Number of Channels 1
Memory Size 512kB Flash 64kB RAM
Data Rate 65Mbps
Protocol 802.11b/g/n
Telecom IC Type TELECOM CIRCUIT
Power - Output 18.3dBm
RF Family/Standard WiFi
Antenna Type Integrated, Chip
Sensitivity -96dBm
Serial Interfaces UART
Current - Receiving 105mA
Current - Transmitting 210mA~344mA
Modulation DSSS, OFDM
Sensitivity (dBm) -96 dBm
Dimensions
Height Seated (Max) 2.45mm
Length 26.924mm
Compliance
Radiation Hardening No
RoHS Status ROHS3 Compliant
Lead Free Lead Free
