WT41U-E-AI55
RoHS
RoHS compliant
RoHS compliantPackage Module
Category RF/IF and RFID / RF Transceiver Modules
Description
BLUETOOTH 2.1+EDR MODULE, CLASS
PDF
/
Buying Options
Total Price: USD $44.12
Unit Price: USD $44.116066
≥1 USD $44.116066
≥200 USD $17.072952
≥500 USD $16.472956
≥1000 USD $16.176241
Inventory: 4262
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 12 Weeks
Physical
Mounting Type Surface Mount
Package / Case Module
Surface Mount YES
Technical
Operating Temperature -40°C~85°C
Packaging Tape & Reel (TR)
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Number of Terminations 59
Additional Feature PITCH TAKEN FROM RECOMMENDED LAND PATTERN
HTS Code 8542.39.00.01
Voltage - Supply 3.3V
Terminal Position QUAD
Terminal Form NO LEAD
Peak Reflow Temperature (Cel) NOT SPECIFIED
Number of Functions 1
Terminal Pitch 1.5mm
Reach Compliance Code compliant
Frequency 2.4GHz
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
JESD-30 Code R-XQMA-N59
Supply Voltage-Max (Vsup) 3.6V
Supply Voltage-Min (Vsup) 3V
Protocol Bluetooth v2.1 + EDR
Power - Output 17dBm
RF Family/Standard Bluetooth
Antenna Type Antenna Not Included, U.FL
Consumer IC Type CONSUMER CIRCUIT
Sensitivity -94dBm
Serial Interfaces UART, USB
Current - Receiving 44mA
Dimensions
Height Seated (Max) 2.45mm
Length 35.3mm
Width 14mm
Compliance
RoHS Status RoHS Compliant
