WT12-A-AI
RoHS
/
Package Module
Category RF/IF and RFID / RF Transceiver Modules
Description
RF TXRX MOD BLUETOOTH CHIP ANT
PDF
/
Buying Options
Total Price: USD $308.4
Unit Price: USD $308.39565
≥1 USD $308.39565
≥10 USD $276.49275
Inventory: 163
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status RoHS Compliant
REACH SVHC No SVHC
Radiation Hardening No
Dimensions
Width 14mm
Length 25mm
Height 2.4mm
Technical
Sensitivity (dBm) -86 dBm
Modulation DQPSK, GFSK
Serial Interfaces PIO, SPI, UART, USB
Sensitivity -86dBm
Antenna Type Integrated, Chip
RF Family/Standard Bluetooth
Power - Output 3dB
Telecom IC Type TELECOM CIRCUIT
Protocol Bluetooth v2.1 + EDR, Class 2
Utilized IC / Part BlueCore4
Data Rate 3Mbps
Max Supply Current 70mA
Memory Size 8MB Flash
Interface SPI, UART, USB
Frequency 2.4GHz
Terminal Pitch 1.5mm
Supply Voltage 3.3V
Number of Functions 1
Terminal Position UNSPECIFIED
Voltage - Supply 3.1V~3.6V
HTS Code 8542.39.00.01
Number of Terminations 31
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Part Status Active
Published 2009
Packaging Strip
Operating Temperature -40°C~85°C
Physical
Number of Pins 31
Package / Case Module
Mounting Type Surface Mount
Mount Surface Mount
Supply Chain
Factory Lead Time 12 Weeks
