BGM123N256V1
RoHS
/
Package 56-SMD Module
Category RF/IF and RFID / RF Transceiver Modules
Description
BGM123 BLUETOOTH SIP MODULE, 3 D
PDF
/
Inventory: 8395
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status RoHS Compliant
Dimensions
Width 6.5mm
Length 6.5mm
Height Seated (Max) 1.4mm
Technical
Modulation GFSK
Current - Transmitting 8.2mA
Current - Receiving 9mA
Serial Interfaces I2C, I2S, SPI, UART
Sensitivity -90dBm
Antenna Type Integrated, Chip
RF Family/Standard Bluetooth
Power - Output 8dBm
Telecom IC Type TELECOM CIRCUIT
Protocol Bluetooth v4.2
Utilized IC / Part EFR32BG
Data Rate 1Mbps
Memory Size 256kB Flash 32kB RAM
JESD-30 Code S-XXMA-N56
Frequency 2.4GHz
Supply Voltage 3.3V
Number of Functions 1
Terminal Form NO LEAD
Terminal Position UNSPECIFIED
Voltage - Supply 1.85V~3.8V
HTS Code 8542.39.00.01
Number of Terminations 56
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Published 2002
Packaging Tray
Operating Temperature -40°C~85°C
Physical
Surface Mount YES
Package / Case 56-SMD Module
Mounting Type Surface Mount
Supply Chain
Factory Lead Time 10 Weeks
