DP1205C915
RoHS
/
Package Module
Category RF/IF and RFID / RF Transceiver Modules
Description
RF TXRX MODULE ISM<1GHZ
PDF
/
Inventory: 6775
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case Module
Technical
Operating Temperature -40°C~85°C
Packaging Tape & Reel (TR)
JESD-609 Code e3
Pbfree Code yes
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 19
Terminal Finish MATTE TIN
HTS Code 8542.39.00.01
Voltage - Supply 2.4V~3.6V
Terminal Position UNSPECIFIED
Terminal Form UNSPECIFIED
Peak Reflow Temperature (Cel) NOT SPECIFIED
Number of Functions 1
Sensitivity (dBm) -118 dBm
Current - Transmitting 33mA~62mA
Current - Receiving 14mA
Serial Interfaces SPI
Antenna Type Antenna Not Included
RF Family/Standard General ISM < 1GHz
Power - Output 15dBm
Telecom IC Type TELECOM CIRCUIT
Utilized IC / Part XE1205
Data Rate 152.3kbps
Qualification Status Not Qualified
JESD-30 Code R-XXMA-X19
Pin Count 19
Base Part Number DP1205
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Frequency 915MHz
Reach Compliance Code unknown
Supply Voltage 3.3V
Compliance
Lead Free Contains Lead
RoHS Status Non-RoHS Compliant
Dimensions
Width 18.5mm
Length 30.5mm
