DP1203C4333LF
RoHS
/
Package Module
Category RF/IF and RFID / RF Transceiver Modules
Description
RF TXRX MODULE ISM
PDF
/
Inventory: 5672
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
Lead Free Lead Free
RoHS Status RoHS Compliant
Dimensions
Width 18.5mm
Length 30.5mm
Technical
Sensitivity (dBm) -111 dBm
Current - Transmitting 33mA~62mA
Current - Receiving 14mA
Serial Interfaces SPI
Antenna Type Antenna Not Included
RF Family/Standard General ISM < 1GHz
Power - Output 11dBm
Telecom IC Type TELECOM CIRCUIT
Utilized IC / Part XE1203
Data Rate 152.3kbps
Qualification Status Not Qualified
Pin Count 21
Base Part Number DP1203
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Frequency 433MHz
Reach Compliance Code unknown
Supply Voltage 3.3V
Number of Functions 1
Peak Reflow Temperature (Cel) NOT SPECIFIED
Terminal Form UNSPECIFIED
Terminal Position UNSPECIFIED
Voltage - Supply 2.4V~3.6V
HTS Code 8542.39.00.01
Terminal Finish MATTE TIN
Number of Terminations 21
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Pbfree Code yes
JESD-609 Code e3
Packaging Tape & Reel (TR)
Operating Temperature -40°C~85°C
Physical
Number of Pins 21
Package / Case Module
Mounting Type Surface Mount
Mount Surface Mount
