ENW-C9A25B1EF image
Favorite
ENW-C9A25B1EF image
Favorite
RoHS
RoHS RoHS compliant
Package PCB Module
Category RF/IF and RFID / RF Transceiver Modules
Description RF TXRX MODULE 802.15.4 U.FL ANT
PDF
/
Inventory: 1803
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Technical

RF Family/Standard 802.15.4
Antenna Type Antenna Not Included, U.FL
Sensitivity -102dBm
Serial Interfaces I2C, UART
Current - Receiving 47mA
Current - Transmitting 72mA
Sensitivity (dBm) -102 dBm
Power - Output 10dBm
Utilized IC / Part MC13213
Data Rate 250kbps
Memory Size 60kB Flash 4kB RAM
Frequency 2.4GHz
Voltage - Supply 2.7V~3.4V
Min Operating Temperature -40°C
Max Operating Temperature 85°C
Moisture Sensitivity Level (MSL) 2 (1 Year)
Part Status Active
Series PAN4561M
Published 2010
Packaging Tape & Reel (TR)
Operating Temperature -40°C~85°C

Compliance

RoHS Status ROHS3 Compliant

Physical

Package / Case PCB Module
Mounting Type Surface Mount
Mount Surface Mount

Supply Chain

Factory Lead Time 16 Weeks
