ENW-89846A1KF
RoHS
RoHS compliant
RoHS compliantPackage Module
Category RF/IF and RFID / RF Transceiver Modules
Description
RF TXRX MOD BLUETOOTH CHIP ANT
PDF
/
Inventory: /
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 16 Weeks
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case Module
Technical
Operating Temperature -40°C~85°C
Packaging Cut Tape (CT)
Published 2014
Series PAN1740
Part Status Active
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Number of Terminations 28
HTS Code 8542.39.00.01
Voltage - Supply 2.35V~3.3V
Terminal Position UNSPECIFIED
Terminal Form UNSPECIFIED
Peak Reflow Temperature (Cel) NOT SPECIFIED
Number of Functions 1
Supply Voltage 3V
Frequency 2.4GHz
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
JESD-30 Code R-XXMA-X28
Interface I2C, SPI, UART
Memory Size 84kB ROM 42kB SRAM
Data Rate 10 kbps
Protocol Bluetooth v4.1, Class 2
Telecom IC Type TELECOM CIRCUIT
Power - Output 0dBm
RF Family/Standard Bluetooth
Antenna Type Integrated, Chip
Serial Interfaces I2C, SPI, UART
Current - Receiving 4.9mA
Modulation FHSS
Sensitivity (dBm) -93 dBm
Dimensions
Height Seated (Max) 2mm
Length 9.5mm
Width 9mm
Compliance
REACH SVHC Unknown
RoHS Status ROHS3 Compliant
Lead Free Lead Free
