ENW-89811K4CF image
Favorite
ENW-89811K4CF image
Favorite
RoHS
/
Package PCB Module
Category RF/IF and RFID / RF Transceiver Modules
Description RF TXRX MOD BLUETOOTH CHIP ANT
PDF
/
Inventory: 3171
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Compliance

Lead Free Lead Free
RoHS Status RoHS Compliant
REACH SVHC No SVHC
Radiation Hardening No

Dimensions

Width 8.7mm
Length 15.6mm
Height 2.8mm

Technical

Sensitivity (dBm) -86 dBm
Modulation DPSK, DQPSK
Current - Transmitting 40mA
Serial Interfaces I2C, JTAG, UART
Sensitivity -88dBm
Antenna Type Integrated, Chip
RF Family/Standard Bluetooth
Power - Output 4.5dBm
Telecom IC Type TELECOM CIRCUIT
Protocol Bluetooth v2.0 + EDR
Data Rate 3Mbps
Interface I2C, UART
Operating Supply Voltage 3.6V
JESD-30 Code R-XXSS-X
Frequency 2.4GHz
Number of Functions 1
Terminal Form UNSPECIFIED
Terminal Position UNSPECIFIED
Voltage - Supply 2.9V~4.1V
Technology CMOS
HTS Code 8542.39.00.01
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Part Status Obsolete
Series PAN1321
Published 2011
Packaging Tape & Reel (TR)
Operating Temperature -40°C~85°C

Physical

Package / Case PCB Module
Mounting Type Surface Mount
Mount Surface Mount

Supply Chain

Factory Lead Time 16 Weeks
