ENW-49A01A3EF
RoHS
RoHS compliant
RoHS compliantPackage Module
Category RF/IF and RFID / RF Transceiver Modules
Description
RF TXRX MODULE WIFI CHIP ANT
PDF
/
Buying Options
Total Price: USD $26.01
Unit Price: USD $26.0128
≥1 USD $26.0128
≥10 USD $24.01256
≥100 USD $22.011616
≥500 USD $20.344104
≥1000 USD $19.343562
Inventory: 485
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
REACH SVHC No SVHC
Technical
Sensitivity (dBm) -98 dBm
Modulation CCK, DSSS, OFDM
Current - Transmitting 350mA~430mA
Current - Receiving 150mA~160mA
Serial Interfaces JTAG, SDIO, SPI, UART
Sensitivity -98dBm
Antenna Type Integrated, Chip
RF Family/Standard WiFi
Power - Output 18dBm
Protocol 802.11b/g/n
Utilized IC / Part 88W8782
Data Rate 150Mbps
Memory Size 1MB Flash
Interface SDIO, SPI, UART
Frequency 2.4GHz
Voltage - Supply 3V~3.6V
Min Operating Temperature -30°C
Max Operating Temperature 70°C
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Part Status Not For New Designs
Series PAN9320
Published 2015
Packaging Tape & Reel (TR)
Operating Temperature -30°C~70°C
Physical
Package / Case Module
Mounting Type Surface Mount
Mount Surface Mount
Supply Chain
Factory Lead Time 16 Weeks
