ZPM3570-E image
Favorite
ZPM3570-E image
Favorite
RoHS
/
Package Module
Category RF/IF and RFID / RF Transceiver Modules
Description Zigbee / 802.15.4 Modules 2.4GHz DSSS 802.15.4
PDF
/
Inventory: 8954
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Compliance

Lead Free Lead Free
RoHS Status RoHS Compliant

Technical

Sensitivity (dBm) -103 dBm
Current - Transmitting 175mA
Current - Receiving 35mA
Serial Interfaces I2C, JTAG, SPI, UART
Sensitivity -103dBm
Antenna Type Integrated, Chip
RF Family/Standard 802.15.4
Power - Output 20dBm
Max Frequency 2.5GHz
Protocol Zigbee?
Utilized IC / Part EM357
Data Rate 250 kbps
Memory Size 8MB Flash
Min Supply Voltage 2.4V
Max Supply Voltage 3.4V
Interface I2C, SPI, UART
Frequency 2.4GHz
Voltage - Supply 2.4V~3.4V
Min Operating Temperature -40°C
Max Operating Temperature 85°C
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Series ZPM
Packaging Bulk
Operating Temperature -40°C~85°C

Physical

Number of Pins 44
Package / Case Module
Mounting Type Surface Mount
Mount Surface Mount
