ZMN2405HP-C
RoHS
/
Package Module
Category RF/IF and RFID / RF Transceiver Modules
Description
RF TXRX MODULE 802.15.4
PDF
/
Inventory: 9316
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status RoHS Compliant
Dimensions
Width 21.21mm
Length 40.64mm
Technical
Sensitivity (dBm) -95 dBm
Modulation DSSS, O-QPSK
Current - Transmitting 130mA
Current - Receiving 33mA
Serial Interfaces SPI, UART
RF Family/Standard 802.15.4
Power - Output 17dBm
Telecom IC Type TELECOM CIRCUIT
Protocol Zigbee?
Utilized IC / Part CC2430
Data Rate 250kbps
Interface SPI, UART
Number of Channels 15
Qualification Status Not Qualified
Pin Count 39
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Frequency 2.4GHz
Reach Compliance Code unknown
Terminal Pitch 1.524mm
Number of Functions 1
Peak Reflow Temperature (Cel) NOT SPECIFIED
Terminal Form NO LEAD
Terminal Position UNSPECIFIED
Voltage - Supply 3.3V~5.5V
Number of Terminations 39
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Series ZMN
Packaging Bulk
Operating Temperature -40°C~85°C
Physical
Number of Pins 39
Package / Case Module
Mounting Type Surface Mount
Mount Surface Mount
