ATZB-S1-256-3-0-UR
RoHS
RoHS compliant
RoHS compliantPackage Module
Category RF/IF and RFID / RF Transceiver Modules
Description
RF TXRX MODULE 802.15.4 U.FL ANT
PDF
/
Inventory: 5415
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
Radiation Hardening No
Dimensions
Width 20mm
Length 30mm
Height Seated (Max) 3.5mm
Technical
Sensitivity (dBm) -97 dBm
Current - Transmitting 9.9mA~16.3mA
Current - Receiving 17mA
Serial Interfaces ISP, JTAG, SPI, UART, USART
Antenna Type Antenna Not Included, U.FL
RF Family/Standard 802.15.4
Power - Output 3.5dBm
Telecom IC Type TELECOM CIRCUIT
Protocol Zigbee?
Data Rate 2Mbps
RAM Size 32kB
Memory Size 256kB Flash 8kB EEPROM 32kB SRAM
Interface SPI, UART, USART
Number of Channels 16
Operating Supply Voltage 3V
JESD-30 Code R-XXMA-N42
Frequency 2.4GHz
Supply Voltage 3V
Number of Functions 1
Terminal Position UNSPECIFIED
Voltage - Supply 1.8V~3.6V
Number of Terminations 42
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
Series ZigBit?
Published 2014
Packaging Bulk
Operating Temperature -40°C~85°C
Physical
Package / Case Module
Mounting Type Surface Mount
Mount Surface Mount
Supply Chain
Factory Lead Time 13 Weeks
