ATWINC1500-MR210PB1944
RoHS
RoHS compliant
RoHS compliantPackage Module
Category RF/IF and RFID / RF Transceiver Modules
Description
ATWINCxx Series 3.6V 72.2 Mbps 2.4GHz IEEE? 802.11 b/g/n SmartConnect IoT Module
PDF
/
Buying Options
Total Price: USD $3.2
Unit Price: USD $3.202163
≥1 USD $3.202163
≥10 USD $3.124702
Inventory: 8634
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 12 Weeks
Physical
Mounting Type Surface Mount
Package / Case Module
Surface Mount YES
Technical
Operating Temperature -40°C~85°C
Packaging Tray
Published 2017
Part Status Active
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Number of Terminations 28
Technology CMOS
Voltage - Supply 2.7V~3.6V
Terminal Position UNSPECIFIED
Terminal Form NO LEAD
Supply Voltage 3.3V
Frequency 2.4GHz
Base Part Number ATWINC1500
JESD-30 Code R-XXMA-N28
Memory Size 4MB Flash 128kB RAM
uPs/uCs/Peripheral ICs Type MICROPROCESSOR CIRCUIT
Data Rate 72.2Mbps
Protocol 802.11b/g/n
Power - Output 18.5dBm
RF Family/Standard WiFi
Antenna Type Integrated, Trace
Sensitivity -95dBm
Serial Interfaces I2C, SPI, UART
Current - Receiving 61mA
Current - Transmitting 265mA
Modulation 16-QAM, 64-QAM, BPSK, CCK, DBPSK, DQPSK, OFDM, QPSK
Firmware Version 19.4.4
Dimensions
Height Seated (Max) 2.113mm
Length 21.72mm
Width 14.73mm
Compliance
RoHS Status ROHS3 Compliant
