ATSAMB11-XR2100A
RoHS
RoHS compliant
RoHS compliantPackage Module
Category RF/IF and RFID / RF Transceiver Modules
Description
with external antenna - SmartConnect ATSAMB11 SiP Module
PDF
/
Buying Options
Total Price: USD $6.63
Unit Price: USD $6.626299
≥1 USD $6.626299
≥10 USD $6.251232
≥100 USD $5.897382
≥500 USD $5.56357
≥1000 USD $5.248648
Inventory: 1523
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
REACH SVHC No SVHC
Dimensions
Width 4.5mm
Length 5.5mm
Height Seated (Max) 1.4mm
Technical
Sensitivity (dBm) -96 dBm
Current - Transmitting 3mA
Current - Receiving 4mA
Serial Interfaces I2C, SPI, UART
Antenna Type Integrated, Chip
RF Family/Standard Bluetooth
Power - Output 4dBm
Telecom IC Type TELECOM CIRCUIT
Screening Level TS 16949
Protocol Bluetooth v4.1
Interface I2C, SPI, UART
Temperature Grade INDUSTRIAL
Operating Temperature (Min) -40°C
Operating Temperature (Max) 85°C
JESD-30 Code R-XBGA-N49
Base Part Number ATSAMB11
Frequency 2.4GHz
Supply Voltage 3.6V
Number of Functions 1
Terminal Form NO LEAD
Terminal Position BOTTOM
Voltage - Supply 2.3V~3.6V
HTS Code 8542.39.00.01
Number of Terminations 49
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Part Status Active
Series SmartConnect
Published 2016
Packaging Tray
Physical
Package / Case Module
Mounting Type Surface Mount
Mount Surface Mount
Supply Chain
Factory Lead Time 16 Weeks
