CC-9P-V524-LX

Digi
RoHS
RoHS RoHS compliant
Package Module
Category RF/IF and RFID / RF Transceiver Modules
Description MODULE 9P 32MB SDRAM 16MB FLASH
PDF
/
Inventory: /
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Supply Chain

Factory Lead Time 12 Weeks

Physical

Mounting Type Surface Mount
Package / Case Module

Technical

Operating Temperature -40°C~85°C
Published 2010
Series ConnectCore? 9P 9215
Part Status Not For New Designs
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Connector Type Socket
Frequency 2.4GHz 5GHz
Operating Supply Voltage 3.3V
Interface I2C, SPI, UART
Memory Size 16MB Flash 32MB SDRAM
RAM Size 32MB
Memory Type FLASH, NOR, SDRAM
Data Rate 54Mbps
Utilized IC / Part NS9215
Protocol 802.11a/b/g
Core Architecture ARM
Power Consumption 1.46W
Power - Output 12dBm
RF Family/Standard WiFi
Antenna Type Antenna Not Included, U.FL
Sensitivity -72dBm
Serial Interfaces Ethernet, I2C, SPI, UART
Modulation 16QAM, 64QAM, BPSK, CCK, DBPSK, DQPSK, QPSK

Dimensions

Height 6.1mm
Length 50mm
Width 50mm

Compliance

Radiation Hardening No
RoHS Status RoHS Compliant
Lead Free Lead Free
