C-MG2470-00
RoHS
RoHS compliant
RoHS compliantPackage 48-VFQFN Exposed Pad
Category RF/IF and RFID / RF Transceiver ICs
Description
Tape & Reel (TR) 22 I2C SPI UART Zigbee? IC RF TxRx + MCU -105dBm 2V~3.6V 9dBm 2.4GHz
PDF
/
Inventory: 955
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Technical
GPIO 22
Number of GPIO 22
Sensitivity (dBm) -105 dBm
Modulation O-QPSK
Current - Transmitting 22.5mA~36.5mA
Current - Receiving 24.9mA
Serial Interfaces I2C, I2S, SPI, UART
Data Rate (Max) 1Mbps
Sensitivity -105dBm
RF Family/Standard 802.15.4
Power - Output 9dBm
Protocol Zigbee?
Memory Size 64kB Flash 1kB ROM 6kB RAM
Interface I2C, SPI, UART
Frequency 2.4GHz
Voltage - Supply 2V~3.6V
Min Operating Temperature -40°C
Max Operating Temperature 85°C
Type TxRx + MCU
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Part Status Active
Packaging Tape & Reel (TR)
Operating Temperature -40°C~85°C
Physical
Supplier Device Package 48-QFN (7x7)
Package / Case 48-VFQFN Exposed Pad
