XWL1831MODGAMOCT

Texas Instruments
RoHS
RoHS RoHS compliant
Package 130-FLGA Module
Category RF/IF and RFID / RF Transceiver ICs
Description MOD 2.4GHZ WIFI BLE WILINK
PDF
/
Inventory: 8802
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Technical

Number of Terminations 100
Type TxRx Only
HTS Code 8542.39.00.01
Voltage - Supply 2.9V~4.8V
Terminal Position BOTTOM
Number of Functions 1
Terminal Pitch 0.7mm
Frequency 2.4GHz
Base Part Number WL1831
JESD-30 Code R-PBGA-N100
Operating Supply Voltage 1.8V
Interface SDIO, UART
Protocol Bluetooth v4.1
Power - Output 17.3dBm
RF Family/Standard Bluetooth
Data Rate (Max) 100Mbps
Serial Interfaces UART
Current - Receiving 85mA
Current - Transmitting 420mA
Modulation GFSK
Sensitivity (dBm) -96.3 dBm
GPIO 13
Moisture Sensitivity Level (MSL) 2 (1 Year)
Part Status Obsolete
Pbfree Code no
Packaging Tape & Reel (TR)
Operating Temperature -40°C~85°C

Dimensions

Height Seated (Max) 2mm

Compliance

Radiation Hardening No
REACH SVHC No SVHC
RoHS Status ROHS3 Compliant
Lead Free Contains Lead

Physical

Number of Pins 130
Surface Mount YES
Package / Case 130-FLGA Module
Mounting Type Surface Mount
