TRF6903PTR
RoHS
RoHS compliant
RoHS compliantPackage 48-LQFP
Category RF/IF and RFID / RF Transceiver ICs
Description
IC RF TXRX ISM<1GHZ 48LQFP
PDF
/
Buying Options
Total Price: USD $4.75
Unit Price: USD $4.74715
≥1 USD $4.74715
≥10 USD $3.89595
≥100 USD $3.7734
≥500 USD $3.6518
≥1000 USD $3.5302
Inventory: 1447
Minimum: 1
-
+
Technical Details
Supply Chain
Lifecycle Status NRND (Last Updated: 3 days ago)
Physical
Mounting Type Surface Mount
Package / Case 48-LQFP
Surface Mount YES
Number of Pins 48
Weight 181.692094mg
Technical
Operating Temperature -40°C~85°C
Packaging Tape & Reel (TR)
JESD-609 Code e4
Pbfree Code yes
Part Status Not For New Designs
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 48
Type TxRx Only
Terminal Finish Nickel/Palladium/Gold (Ni/Pd/Au)
HTS Code 8542.39.00.01
Subcategory Other Telecom ICs
Technology CMOS
Voltage - Supply 2.2V~3.6V
Terminal Position QUAD
Terminal Form GULL WING
Peak Reflow Temperature (Cel) 260
Number of Functions 1
Supply Voltage 2.7V
Terminal Pitch 0.5mm
Depth 7.2mm
Frequency 315MHz 433MHz 868MHz 915MHz
Base Part Number TRF6903
Pin Count 48
Power Supplies 2.5/3.3V
Power - Output 8dBm
RF Family/Standard General ISM < 1GHz
Data Rate (Max) 64kbps
Serial Interfaces SPI
Current - Receiving 10mA~20mA
Current - Transmitting 10mA~37mA
Modulation ASK, FSK, OOK
Dimensions
Height 1.6mm
Length 7mm
Width 7mm
Thickness 1.4mm
Compliance
Radiation Hardening No
RoHS Status ROHS3 Compliant
Lead Free Lead Free
