TRF6901PTG4
RoHS
RoHS compliant
RoHS compliantPackage 48-LQFP
Category RF/IF and RFID / RF Transceiver ICs
Description
IC RF TXRX ISM<1GHZ 48LQFP
PDF
/
Inventory: 8626
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
Lead Free Contains Lead
RoHS Status ROHS3 Compliant
Radiation Hardening No
Dimensions
Length 7mm
Height Seated (Max) 1.6mm
Technical
Modulation ASK, FSK, OOK
Current - Transmitting 26mA~32mA
Current - Receiving 18mA
Serial Interfaces SPI
Data Rate (Max) 64kbps
RF Family/Standard General ISM < 1GHz
Power - Output 8dBm
Operating Supply Voltage 3.3V
Pin Count 48
Base Part Number TRF6901
Frequency 860MHz~930MHz
Depth 7mm
Terminal Pitch 0.5mm
Supply Voltage 2.7V
Number of Functions 1
Peak Reflow Temperature (Cel) 260
Terminal Form GULL WING
Terminal Position QUAD
Voltage - Supply 1.8V~3.6V
HTS Code 8542.39.00.01
Terminal Finish Nickel/Palladium/Gold (Ni/Pd/Au)
Type TxRx Only
Number of Terminations 48
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Pbfree Code yes
JESD-609 Code e4
Packaging Tray
Operating Temperature -40°C~85°C
Physical
Weight 181.692094mg
Number of Pins 48
Surface Mount YES
Package / Case 48-LQFP
Mounting Type Surface Mount
